AB 1794-OA16 Analog Output Module: Precision Control for Industrial Automation
The AB 1794-OA16 is an advanced modular analog output control unit designed for precise control over various industrial processes, offering seamless integration and reliable performance in demanding environments.
Detailed content
Model Number:1794-OA16
Type:Analog Output
Power Supply:12-24VDC
Channels:16
Current Rating:10mA per channel
Resolution:12 bits
Communication Interface:Modbus RTU
Operating Temperature:-20°C to +60°C
Storage Temperature:-40°C to +70°C
Dimensions:W x H x D: 114 x 91.4 x 27.9mm
Weight:0.2kg
The AB 1794-OA16 is engineered to withstand the harshest industrial environments, ensuring reliable operation under extreme temperatures and conditions.
Each channel is capable of delivering a current rating of up to 25mA, making it suitable for a wide range of load types, including solenoids, relays, and small motors.
Equipped with Modbus RTU communication protocol, this module seamlessly integrates with Allen-Bradley PLC systems, facilitating easy setup and configuration through an internal web server.
Featuring a 4-character, alpha-numeric, scrolling LED display, users can monitor the status and diagnostics data in plain English without the need for complex error codes.
The inclusion of ProSoft Discovery Service (PDS) software ensures quick identification and configuration on the network, minimizing downtime during installation and maintenance.
